BUILD VOLUME
250 x 250 x 325 mm (9.8 x 9.8 x 12.8 in)
LASER TYPE
Yb-fiber laser; 1 x 400 W
PRESICION OPTICS
1 F-theta-lens(es); 1 High-speed scanner(s)
SCAN SPEED
up to 7.0 m/s (23.0 ft/s)
FOCUS DIAMETER
approx. 100 µm (0.00394 in)
POWER SUPPLY
1 x 32 A
POWER CONSUMPTION
max. 8.5 kW / typical 2.4 kW
COMPRESSED AIR SUPPLY
7 Bar; 20 m³/h (102 psi; 706 ft³/h)
MACHINE DIMENSIONS
2500 x 1300 x 2190 mm (98.4 x 51.2 x 86.2 in)
RECOMMENDED INSTALLATION SPACE
min. 4800 x 3600 x 2900 mm (189.0 x 141.7 x 114.2 in)
WEIGHT
approx. 1250 kg (2756 lbs)
SOFTWARE
EOS BUILD , EOS SMART MONITORING , EOS SYSTEM SUITE
Materials & Processes
The EOS M 290 has the most extensive range of validated
materials and processes on the market. EOS metal materials
are designed specifically for DMLS and are quality controlled.
EOS processes are validated ensuring consistent and repeatable
part quality. Explore below which metal materials and
processes are compatible with the EOS M 290.
This equipment has been sold. Similar equipment available now is shown below.
